The very best in rotary mulching technology has been packed into the Stubble Master 500, a premium five metre cutting width machine targeted at high output farmers and contract professionals demanding high levels of quality and performance.

The shaft driven machine benefits from Spearhead’s unique six-blade Starcut blade system as standard which; when coupled with the efficient delta wing design of the cutting deck provides a chop and spread of the highest standard.

Much of the appeal of the Stubble Master 500 is that it has been built without any compromise, mirroring many of the principles seen in the machines much larger in size in the same range.

Featuring three rotors, each with heavy duty blade holders and six robust 13 millimetre thick spring steel blades – three high lift and three flat for extra mulching, the machine is capable of leaving a flail type finish to support a more efficient harvest operation and an improved yield.

Image shows high-lift blade configuration using cutting and mulching technology.

Video

Watch the video


AGRICULTURE
PASTURE
LIGHT SCRUB
HEAVY SCRUB
STUBBLE MANAGEMENT
AIRFIELD

Features

  • 5.0 metre cutting width
  • 120hp minimum tractor requirement
  • Heavy duty 250hp input gearbox
  • Heavy duty 111hp rotor gearboxes
  • Slip clutch protection
  • 8 large pneumatic rear wheels
  • Anti-scalp rotor protection dishes
  • 18 x heavy duty cutting blades (6 per rotor)
  • Floating wings
  • Rear lighting kit


DRIVELINE ASSEMBLY BONDIOLI STUBBLE MASTER 500-730

DRIVELINE ASSEMBLY BONDIOLI STUBBLE MASTER 500-730

Specifications

STUBBLE MASTER 500

Machine weight*: 2920kg/6438lbs With front and rear single chain guards
Hitch: Multi-positional drawbar
Cutting width: 5.06m/199″
Working machine width: 5.20m/205″
Transport machine width: 2.97m/117″
Maximum working length: 5.83m/230″
Transport length: 5.78m/228″
Deck height**: 0.26m/10″
Cutting height: 25mm-400mm (1″ – 16″)
Cutting capacity: 100mm/4″ DIA
Wing working angles: 30° up/7.5° down
Recommended tractor HP: 120hp/89kW
Power take-off speed: 1000rpm
Gearbox [Splitter gearbox]: Cast iron housing
Gearbox [Centre rotor gearbox]: Cast iron housing
Gearbox [Wing rotor gearboxes (x2)]: Cast iron housing
Gearbox [Input shaft]: 1″ 3/8 Z21 or Z6 SFT 6 tractor end or 1″ 3/4 Z20 or Z6 SFT tractor end
Gearbox lubricant: EP80-90W oil
Gearbox oil capacity [Splitter Gearbox]: 2.65 litres/4.66 pints
Gearbox oil capacity [Wing Rotor Gearboxes (x2)]: 2.1 litres/3.65 pints
Deck construction: All welded construction
Deck material thickness: 3mm (1/8″)
Side skirt material thickness: 8mm (5/16″)
Skid construction: Replaceable bolt on skid shoes
Anti-scalp dish: 5mm (3/16″) with blade holder bar
Blades Standard (x9): 12mm (1/2″) 30 Carbon Boron hardened and tempered. Free swinging high lift – low friction. Handed.
Blades Starcut (x9): 12mm (1/2″) 30 Carbon Boron hardened and tempered. Free swinging high lift – low friction. Non-Handed.
Blade bolts: M24 C/W shank grade 8.8
Blade tip speed: 80 mps/15748 fpm
Driveline: ASAE category 4
Driveline protection: 2-way slip clutch on rotor gearboxes. Overrun on input shaft
Tailwheel mount assembilies: Tubular welded walking axles
Tailwheels (x8): 7.00-12 pneumatic tyre with steel hub
Front guard: Single chain guards on each deck
Rear guard: Single chain guards on each deck

*With front and rear single chain guards
**Underside of deck to skid

Stubble Master 500

Machine weight*: 2920kg/6438lbs With front and rear single chain guards
Hitch: Multi-positional drawbar
Cutting width: 5.06m/199″
Working machine width: 5.20m/205″
Transport machine width: 2.97m/117″
Maximum working length: 5.83m/230″
Transport length: 5.78m/228″
Deck height**: 0.26m/10″
Cutting height: 25mm-400mm (1″ – 16″)
Cutting capacity: 100mm/4″ DIA
Wing working angles: 30° up/7.5° down
Recommended tractor HP: 120hp/89kW
Power take-off speed: 1000rpm
Gearbox [Splitter gearbox]: Cast iron housing
Gearbox [Centre rotor gearbox]: Cast iron housing
Gearbox [Wing rotor gearboxes (x2)]: Cast iron housing
Gearbox [Input shaft]: 1″ 3/8 Z21 or Z6 SFT 6 tractor end or 1″ 3/4 Z20 or Z6 SFT tractor end
Gearbox lubricant: EP80-90W oil
Gearbox oil capacity [Splitter Gearbox]: 2.65 litres/4.66 pints
Gearbox oil capacity [Wing Rotor Gearboxes (x2)]: 2.1 litres/3.65 pints
Deck construction: All welded construction
Deck material thickness: 3mm (1/8″)
Side skirt material thickness: 8mm (5/16″)
Skid construction: Replaceable bolt on skid shoes
Anti-scalp dish: 5mm (3/16″) with blade holder bar
Blades Standard (x9): 12mm (1/2″) 30 Carbon Boron hardened and tempered. Free swinging high lift – low friction. Handed.
Blades Starcut (x9): 12mm (1/2″) 30 Carbon Boron hardened and tempered. Free swinging high lift – low friction. Non-Handed.
Blade bolts: M24 C/W shank grade 8.8
Blade tip speed: 80 mps/15748 fpm
Driveline: ASAE category 4
Driveline protection: 2-way slip clutch on rotor gearboxes. Overrun on input shaft
Tailwheel mount assembilies: Tubular welded walking axles
Tailwheels (x8): 7.00-12 pneumatic tyre with steel hub
Front guard: Single chain guards on each deck
Rear guard: Single chain guards on each deck

*With front and rear single chain guards
**Underside of deck to skid
